Logic

Legends

Propositional Symbols

Symbol	Meaning
¬P	NOT P (negation)
P ∧ Q	P AND Q (conjunction)
P ∨ Q	P OR Q (inclusive OR)
P ⊕ Q	Exclusive OR (exactly one true)
P → Q	If P then Q (implication)
P ↔ Q	P iff Q (biconditional)
⊤ / ⊥	Always true / always false

Predicate Symbols

Symbol	Meaning
∀x	For all x (universal quantifier)
∃x	There exists an x (existential quantifier)
P(x)	Predicate P applied to argument x
R(x,y)	Relation R between x and y
x = y	Equality: x and y refer to the same object
f(x)	Function term f applied to x
¬P(x)	Negation of predicate statement P(x)
∀x P(x)	P holds for every x in the domain
∃x P(x)	P holds for at least one x in the domain

Quantifier Symbols

Symbol	Meaning
∀	Universal quantifier: “for all”
∃	Existential quantifier: “there exists”
∀x P(x)	P(x) is true for every x in the domain
∃x P(x)	There is at least one x in the domain where P(x) is true
∀x∈D P(x)	For every x in set/domain D, P(x) holds
∃x∈D P(x)	There exists an x in set/domain D such that P(x) holds
¬∀x P(x)	Not all x satisfy P(x) (equivalent to ∃x ¬P(x))
¬∃x P(x)	No x satisfies P(x) (equivalent to ∀x ¬P(x))

Set Symbols

Symbol	Meaning
∈	Is an element of
∉	Is not an element of
⊆	Subset of (possibly equal)
⊂	Proper subset of
⊇	Superset of (possibly equal)
∪	Union of sets
∩	Intersection of sets
A \ B	Set difference: elements in A not in B
A △ B	Symmetric difference
∅	Empty set
\|A\|	Cardinality (number of elements in A)
𝒫(A)	Power set of A (all subsets of A)

Relation Symbols

Symbol	Meaning
xRy	x is related to y by relation R
(x,y) ∈ R	Ordered pair (x,y) belongs to relation R
R ⊆ A×A	R is a relation on set A
R⁻¹	Inverse relation of R
R∘S	Composition of relations R and S
Idₐ	Identity relation on A
Reflexive	∀x, xRx
Symmetric	∀x∀y, xRy → yRx
Antisymmetric	∀x∀y, (xRy ∧ yRx) → x=y
Transitive	∀x∀y∀z, (xRy ∧ yRz) → xRz

Function Symbols

Symbol	Meaning
f: A → B	Function f maps elements from domain A to codomain B
f(x)	Value of function f at input x
x ↦ f(x)	Rule notation: x maps to f(x)
dom(f)	Domain of f (all allowed inputs)
codom(f)	Codomain of f (declared output set)
im(f)	Image/range of f (actual outputs produced)
f⁻¹	Inverse function (exists when f is bijective)
(f∘g)(x)	Composition: apply g first, then f
Injective	One-to-one: different inputs give different outputs
Surjective	Onto: every codomain element is hit
Bijective	Both injective and surjective

Lab

Designed and Developed by Franz Ayestaran / Enhanced Pair Programming with OpenAI GPT

Logic Wiki

Use the search + dropdown in the left sidebar to browse LogicWiki topics.

Interactive Logic Gates Tutorial

Explore AND, OR, NOT, NAND, NOR, and XOR. Switch inputs to see outputs and compare with each gate truth table.

Gate A B

AND gate from the Gates folder.

Propositional Logic

Predicate Logic

Quantifiers
